10-in-1 USB-C Multiport Adapter
UCM-2005
- 10-in-1 Solution: connect 9 devices and charge your USB-C host device simultaneously
- Crystal clear 4K Ultra HD video and audio
- Connect 2 USB-A devices & 1 USB-C device to a USB-C device (e.g., notebook, MacBook, tablet, smartphone)
- Connect 2 HDMI displays to a USB-C device
- Connect 2 displays in Single Stream Transport (SST) or Multi-Stream Transport (MST) mode
- Read and write SD and MicroSD cards
- Connect to a wired Gigabit network with a USB-C device
- Connect any audio device (3.5mm plug)
- Simultaneous fast charging of your USB-C host device thanks to 100W USB-C PD
- Fast and reliable file transfer speed (5Gbps)
- Easy Plug & Play, no setup/drivers needed
- Reversible ultra-slim USB-C plug design
- Durable aluminium housing
- Compatible with all major operating systems
Related products
User Manual
Declarations of Conformity
More Support
Frequently Asked Questions: UCM-2005
Please check our FAQs to find answers and solutions to common questions.
My product is faulty. What can I do?
We offer a ‘return to the retailer’ warranty on our products. In case of a defect, please return the product to your retailer with a clear description of the problem, proof of purchase, and all accessories. During the warranty period, you will receive a replacement product from the retailer if available.
Specifications
Ports
| Input | USB-C |
| 2 x USB-A Output | 5Gbps data / 7.5W power |
| 1 x USB-C Output | 5Gbps data / 7.5W power |
| 2 x HDMI 2.0 Output | Yes |
| 1 x DisplayPort 1.2 | Yes |
| 1 x SD Card Reader Slot | Yes |
| 1 x MicroSD Card Reader Slot | Yes |
| 1 x RJ45 Gigabit LAN Output | Yes |
| 1 x 3.5mm Audio Output | Yes |
| 1 x USB-C Power Delivery 100W (20V/5A) pass-through | Yes |
Features
| USB 3.2 Gen 1 | Superspeed USB |
| USB Battery Charging | 1.2 up to 7.5W (5V/1.5A) |
| Resolution | Up to 3840x2160 @60Hz |
| Multi-Stream Transport (MST) Support: | Extend and Mirror Mode |
| Supports | Secure Digitalv1.0/v1.1/v2.0/SDHC/SDXC up to 2TB |
| Supports | Secure Digital v3.01 UHS-I (SDR12/SDR25/SDR50/DDR50/SDR104) |
| Supports | MultiMediaCard (MMC) v3.x/v4.0/v4.1/ 4.2 |
| Auto-detection | 10/100/1000Mbps |
| Supports | Wake-on-LAN |
| Supports | 16-bit/48kHz |
| Plug & Play | No software needed |
| Integrated cable | 18 cm |
Compatibility
| USB-C port | (PD & DP Alt Mode) |
| USB-C PD charger & cable | |
| Compatible with | All major operating systems |
Dimensions
| Height | 15 mm |
| Width | 115 mm |
| Depth | 60 mm |
| Weight | 106 g |
